RS-R Best*I Active Coilover Suspension System – 2024–2025 Acura Integra Type S

Description

Part Number: XBIH093MA Compatibility: 2024+ Acura Integra Type S Chassis code: DE5

Preset Approximate Height

Front: -20mm to -25mm (-0.8in to -1.0in) Rear: -20mm to -25mm (-0.8in to -1.0in)

Maximum Adjustment Range

Front: +10mm to -50mm (+0.4in to -2.0in) Rear: -5mm to -50mm (-0.2in to -2.0in)

Recommended Adjustment Range

Front: 0mm to -45mm (0in to -1.8in) Rear: -5mm to -50mm (-0.2in to -2.0in)

Spring Rate

Front: 8.00kg/mm Rear: 6.00kg/mm

Additional Information

Warranty: 1 Year / 12,000 miles from the day of purchase Included but not pictured: hex and allen wrench, rubber and poly seat for rear adjuster, flange nut for rear, zip ties, harness for rear
