Description
- Single 2-Port Compact Baffled Oil Catch Can with application-specific lid mounts in line with the CCV system to separate oil particles using 50 micron bronze filter
- Application-specific bracket mounts the can in a serviceable location
- Direct fit hoses allow for installation with no modification to engine cover
- Application-specific lid designed so fitting size matches CCV line size
- Billet 6061 aluminum sealed can
- Defends intercooler, intake system, and VANOS system from oil blow-by
- Helps maintain proper octane levels to reduce potential detonation
- Filters and can is fully serviceable
- Internal air diverter turbulates air longer to improve oil separation
- Mishimoto Lifetime Warranty
Overall Height 3.8″
Overall Diameter 2.5″
Inlet 3/8″ NPT
Outlet 3/8″ NPT
Drain Plug Thread Size 3/8″ NPT
Capacity 2 fl oz
Assembled Weight 0.9 lbs
Purchase Includes (1) Application-Specific Mounting Bracket
(1) Black, Anodized 6061 Aluminum Catch Can
(2) Direct Fit Hoses, Black
(2) Plastic Barbed Fittings
(1) Air Diverter
(1) Internal Baffle & Rod
(1) 3/8″ NPT Plug
(1) Large O-Ring
Mounting Hardware Mishimoto Lifetime Warranty
Fits 2008–2010 BMW E82 135i
2011 BMW E82 1M
2006–2010 BMW E90 335i/335xi
2006–2010 BMW E91 335i/335xi
2007–2010 BMW E92 335i/335xi
2007–2010 BMW E93 335i/335xi
Engine Codes N54
Chassis Codes E82
E90
E91
E92
E93
Material 6061 Aluminum
Install Torque Specs 22 in-lbs (2.5N*M) recommended for all worm-gear clamps. These clamps have an operating range of 18-27 in-lbs 2-3N*M. Do not exceed the maximum torque rating of 27 in-lbs (3N*M).
Note After installation, Mishimoto recommends checking the contents of the baffled catch cans every 1,000 miles until a baseline is established. Oil blow-by accumulation will vary with ambient temperatures and driving conditions. It is important that the contents of the can do not rise above the internal baffle
Color BK
Baffled Yes
